4JH45 Overview

Specifications

Rated Output	33.1 kW / 45mhp
Rated Speed	3000 rpm
Displacement	2.19 L / 131 cu. in
No. of Cylinders	4 Cylinders
Cylinder Bore x Stroke	88 mm x 90 mm / 3.46 in x 3.54 in
Combustion System	Direct Injection, Bosch Common Rail System
Aspiration	Natural
Alternator	12V - 125A
Dry Weight Without Gear	220 kg / 485 Ibs
Dimensions	870 mm x 589 mm x 627 mm
Controls	Mechanical (Optional - VC10 System)
Certifications	RCD 2 \| EPA Tier 3 \| EPA Tier 3C \| BSO II \| EMC \| SOLAS
