1GM10 Overview
Specifications
| Rated Output | 6.6 kW / 9mhp |
| Rated Speed | 3600 rpm |
| Displacement | 0.318 L / 19.41 cu. in |
| No. of Cylinders | 1 Cylinders |
| Cylinder Bore x Stroke | 75 mm x 72 mm / 2.95 in x 2.83 in |
| Combustion System | Indirect Injection, In-line Pump |
| Aspiration | Natural |
| Alternator | 12V - 40A |
| Dry Weight Without Gear | 71 kg / 156.5 Ibs |
| Dimensions | 554 mm x 410 mm x 485 mm |
| Controls | Mechanical |
| Certifications | RCD 2 | EPA Tier 2 | BSO II | EMC |
NOTE:
1 kW = 1.3596 mhp = 1.34102 bhp
Fuel condition: at 15°C =0.842 g/cm³
Technical data according to (ISO 8665) / (ISO3046)
Fuel temperature 40°C at the inlet of the fuel injection pump (ISO 8665)
Length includes KM35A marine gear
(Dimensions may vary with other gears/ elbow)
